%45 réduit

Type 22H Radiateur Décoratif 514x600 Noir mat

Name: Type 22H Radiateur Décoratif 514x600 Noir mat
SKU: 222H05140600B3MS
Price: 17452.05 TRY
Availability: InStock

Code De Produit : 222H05140600B3MS

Garantie : 10 Année

TAXES INCLUSES

Prix

31.731,00 TL

Prix réduit

17.452,05 TL

10 ans
Garantie

2000€ +
Livraison gratuite

{"vat":20,"m_o_p":0,"variant_ids":{"60_0":"8190","59_0":"10935","58_0":"13680","57_0":"16425","56_0":"17685","55_0":"18945","54_0":"20205","53_0":"21321","52_0":"21657"},"variant_prices":{"60_0":14543.375,"59_0":15423.375,"58_0":15423.375,"57_0":15423.375,"56_0":15423.375,"55_0":15423.375,"54_0":15423.375,"53_0":15423.375,"52_0":15423.375},"variant_price_raws":{"60_0":14543.375,"59_0":15423.375,"58_0":15423.375,"57_0":15423.375,"56_0":15423.375,"55_0":15423.375,"54_0":15423.375,"53_0":15423.375,"52_0":15423.375},"buying_prices":{"60_0":"0","59_0":"0","58_0":"0","57_0":"0","56_0":"0","55_0":"0","54_0":"0","53_0":"0","52_0":"0"},"not_discounted_prices":{"60_0":"26442.5","59_0":"28042.5","58_0":"28042.5","57_0":"28042.5","56_0":"28042.5","55_0":"28042.5","54_0":"28042.5","53_0":"28042.5","52_0":"28042.5"},"variant_supplier_codes":{"60_0":"222H05140600B3MS","59_0":"222H05140600B3MM2","58_0":"222H05140600B3MM3","57_0":"222H05140600B3MM1","56_0":"222H05140600B3MY0","55_0":"222H05140600B3MC1","54_0":"222H05140600B3MC2","53_0":"222H05140600B3MR2","52_0":"222H05140600B3ML2"},"active_ids":{"one_60":["0"],"two_0":["60","59","58","57","56","55","54","53","52"],"one_59":["0"],"one_58":["0"],"one_57":["0"],"one_56":["0"],"one_55":["0"],"one_54":["0"],"one_53":["0"],"one_52":["0"]},"variant_informations":{"60_0":{"additional_information":""},"59_0":{"additional_information":""},"58_0":{"additional_information":""},"57_0":{"additional_information":""},"56_0":{"additional_information":""},"55_0":{"additional_information":""},"54_0":{"additional_information":""},"53_0":{"additional_information":""},"52_0":{"additional_information":""}},"variant_stocks":{"60_0":"100","59_0":"100","58_0":"100","57_0":"100","56_0":"99","55_0":"100","54_0":"100","53_0":"100","52_0":"100"}}

Options de axe

Entrée Standard

Bas à droite 50mm

Bas à gauche 50mm

Bas Milieu 50mm

Côté-Bas Droite Bas Gauche

Croix-gauche en bas en haut à droite

Croisé en haut à gauche en bas à droite

514 Dek Radyator Yan-45cm Giriş Sağ

514 Dek Radyator Yan-45cm Giriş Sol

Choisissez la quantité

Ajouter Au Panier

Livraison Prévue

21.01.2025 (60 Jours)

Ajouter Un Commentaire Alerte Prix Ajouter À Ma Liste De Courses

Caractéristiques Du Produit
Téléchargements
Les Options De Paiement
Commentaires (0)

INFORMATIONS TECHNINQUES
• Model = 22H

• Matériel =Acier

• Hauteur=292 mm

• Largeur=2600 mm

• Couleur / Revêtement=Matte Black RAL9005

• Nombre de sections=4 Pièces

• Nombre total de profils=4+4 Pièces

• Dimensions des profils=70x11 mm

• Dimension du collecteur=30x80 mm

• Pression de service maximale=4,5 bar

• Profondeur du radiateur=100 mm

• Du mur au centre de l'entrée=85 mm

• Distance entre mur et surface devant =135 mm

• Dimension du filetage du radiateur=1/2"

• Volume d'eau=11,3 lt

• Weight=46,1 kg

• Poids brute=48,68 kg

• Dimension de carton=35x266x13,6 cm

TAPPING OPTIONS

• Entrée Standard=2550 mm

• Entrée du bas au milieu=50mm

• Entrée du bas a droite=50mm

• Entrée du bas a gauche=50mm

• Côtés / Bas Droite-Gauche=2690mm

• Croix en haut à droite / en bas à gauche=2690mm

• Croix haut-gauche / bas-droite=2690mm

• Côté - droit=250mm

• Côté - gauche=250mm

Puissance thérmique

Kcal / h

• Puissance thérmique75/65-20°?t=50°C = 2206 Kcal/h

• Puissance thérmique90/70-20° ?t=60°C=2780Kcal/h

• Puissance thérmique55/45-20° ?t=30°C=1130Kcal/h

Watts

• Puissance thérmique75/65-20°?t=50°C=2564 Watt

• Puissance thérmique90/70-20°?t=60°C=3231 Watt

• Puissance thérmique55/45-20°?t=30°C=1313 Watt

Btu

• Puissance thérmique75/65-20°?t=50°C=8749 Btu

• Puissance thérmique90/70-20°?t=60°C=11024 Btu

• Puissance thérmique55/45-20°?t=30°C=4480 Btu
