DL 2 Column Radiator 1000x1176 Anthracite

Product Code : 2D2C10001176B2TS
Guarantee : 10 Year
TAXES Included
Price
:
101,290.50 TL
Discounted Price
:
55,709.78 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
Options

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
06.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 2K

    • Material  = Steel

    • Height = 1000 mm

    • Width   = 1176 mm

    • Color = Anthracite

    • Number of Columns = 2

    • Number of Sections  = 25 Pieces

    • Legs Needed If Free Standing = 3 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 67 mm

    • Wall Projection Distance  = 100 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 66 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 25 lt

    • Radiator Weight    = 37,5 kg

    TAPPING OPTIONS



    • Standard Entry1    = 930 mm

    • Standard Entry Cross = 1266 mm

    • Sides / Bottom Right-Left  = 1266 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 1551 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 1955 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 795 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 1803 Watt

    • Heat Output 90/70-20° ∆t=60°C = 2272 Watt

    • Heat Output 55/45-20° ∆t=30°C = 924 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 6152 Btu

    • Heat Output 90/70-20° ∆t=60°C = 7752 Btu

    • Heat Output 55/45-20° ∆t=30°C = 3150 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
