DL 2 Column Radiator 1500x992 Matt Black

Product Code : 2D2C15000992B3MS
Guarantee : 10 Year
TAXES Included
Price
:
127,276.92 TL
Discounted Price
:
70,002.31 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
INSTALLATION CONNECTION OPTIONS

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
05.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 2K

    • Material  = Steel

    • Height = 1500 mm

    • Width   = 992 mm

    • Color = Matt Black

    • Number of Columns = 2

    • Number of Sections  = 21 Pieces

    • Legs Needed If Free Standing = 3 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 67 mm

    • Wall Projection Distance  = 100 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 66 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 29,4 lt

    • Radiator Weight    = 46,2 kg

    TAPPING OPTIONS



    • Standard Entry1    = 1430 mm

    • Standard Entry Cross = 1082 mm

    • Sides / Bottom Right-Left  = 1082 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 1915 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 2413 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 981 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 2226 Watt

    • Heat Output 90/70-20° ∆t=60°C = 2805 Watt

    • Heat Output 55/45-20° ∆t=30°C = 1140 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 7596 Btu

    • Heat Output 90/70-20° ∆t=60°C = 9571 Btu

    • Heat Output 55/45-20° ∆t=30°C = 3890 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
