  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 2K

    • Material  = Steel

    • Height = 600 mm

    • Width   = 532 mm

    • Color = Anthracite

    • Number of Columns = 2

    • Number of Sections  = 11 Pieces

    • Legs Needed If Free Standing = 2 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 67 mm

    • Wall Projection Distance  = 100 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 66 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 7,7 lt

    • Radiator Weight    = 9,9 kg

    TAPPING OPTIONS



    • Standard Entry1    = 530 mm

    • Standard Entry Cross = 622 mm

    • Sides / Bottom Right-Left  = 622 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 424 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 535 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 218 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 493 Watt

    • Heat Output 90/70-20° ∆t=60°C = 622 Watt

    • Heat Output 55/45-20° ∆t=30°C = 253 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 1683 Btu

    • Heat Output 90/70-20° ∆t=60°C = 2121 Btu

    • Heat Output 55/45-20° ∆t=30°C = 862 Btu
