Dl 2 Column Radiator 600x992 Anthracite

Product Code : 2D2C06000992B2TS
Guarantee : 10 Year
TAXES Included
Price
:
71,404.74 TL
Discounted Price
:
39,272.61 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
Choose Quantity
Planned Delivery
:
05.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)
  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 2K

    • Material  = Steel

    • Height = 600 mm

    • Width   = 992 mm

    • Color = Anthracite

    • Number of Columns = 2

    • Number of Sections  = 21 Pieces

    • Legs Needed If Free Standing = 3 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 67 mm

    • Wall Projection Distance  = 100 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 66 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 14,7 lt

    • Radiator Weight    = 18,9 kg

    TAPPING OPTIONS



    • Standard Entry1    = 530 mm

    • Standard Entry Cross = 1082 mm

    • Sides / Bottom Right-Left  = 1082 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 810 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 1021 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 415 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 941 Watt

    • Heat Output 90/70-20° ∆t=60°C = 1186 Watt

    • Heat Output 55/45-20° ∆t=30°C = 482 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 3211 Btu

    • Heat Output 90/70-20° ∆t=60°C = 4046 Btu

    • Heat Output 55/45-20° ∆t=30°C = 1645 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day
  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.



Other Colors
