DL 2 Column Radiator 900x2740 Matt Black

Product Code : 2D2C09002740B3MS
Guarantee : 10 Year
TAXES Included
Price
:
222,730.56 TL
Discounted Price
:
122,501.81 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
INSTALLATION CONNECTION OPTIONS

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
06.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 2K

    • Material  = Steel

    • Height = 900 mm

    • Width   = 2740 mm

    • Color = Matt Black

    • Number of Columns = 2

    • Number of Sections  = 59 Pieces

    • Legs Needed If Free Standing = 4 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 67 mm

    • Wall Projection Distance  = 100 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 66 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 53,1 lt

    • Radiator Weight    = 82,6 kg

    TAPPING OPTIONS



    • Standard Entry1    = 830 mm

    • Standard Entry Cross = 2830 mm

    • Sides / Bottom Right-Left  = 2830 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 3304 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 4164 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 1692 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 3841 Watt

    • Heat Output 90/70-20° ∆t=60°C = 4840 Watt

    • Heat Output 55/45-20° ∆t=30°C = 1967 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 13106 Btu

    • Heat Output 90/70-20° ∆t=60°C = 16514 Btu

    • Heat Output 55/45-20° ∆t=30°C = 6711 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
