COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 3K
• Material = Steel
• Height = 1500 mm
• Width = 716 mm
• Color = Anthracite
• Number of Columns = 3
• Number of Sections = 15 Pieces
• Legs Needed If Free Standing = 2 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 87,5 mm
• Wall Projection Distance = 141 mm
• Section Width = 46 mm
• Radiator Depth = 107 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 30 lt
• Radiator Weight = 40,5 kgTAPPING OPTIONS
• Standard Entry1 = 1430 mm
• Standard Entry Cross = 806 mm
• Sides / Bottom Right-Left = 806 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 1858 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 2342 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 952 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 2160 Watt
• Heat Output 90/70-20° ∆t=60°C = 2722 Watt
• Heat Output 55/45-20° ∆t=30°C = 1106 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 7370 Btu
• Heat Output 90/70-20° ∆t=60°C = 9287 Btu
• Heat Output 55/45-20° ∆t=30°C = 3774 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
