COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 3K
• Material = Steel
• Height = 300 mm
• Width = 624 mm
• Color = Anthracite
• Number of Columns = 3
• Number of Sections = 13 Pieces
• Legs Needed If Free Standing = 2 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 87,5 mm
• Wall Projection Distance = 141 mm
• Section Width = 46 mm
• Radiator Depth = 107 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 7,8 lt
• Radiator Weight = 6,5 kgTAPPING OPTIONS
• Standard Entry1 = 230 mm
• Standard Entry Cross = 714 mm
• Sides / Bottom Right-Left = 714 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 371 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 468 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 190 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 431 Watt
• Heat Output 90/70-20° ∆t=60°C = 544 Watt
• Heat Output 55/45-20° ∆t=30°C = 221 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 1471 Btu
• Heat Output 90/70-20° ∆t=60°C = 1854 Btu
• Heat Output 55/45-20° ∆t=30°C = 754 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
