COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 5K
• Material = Steel
• Height = 300 mm
• Width = 624 mm
• Color = Matt Black
• Number of Columns = 5
• Number of Sections = 13 Pieces
• Legs Needed If Free Standing = 2 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 128,5 mm
• Wall Projection Distance = 223 mm
• Section Width = 46 mm
• Radiator Depth = 189 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 13 lt
• Radiator Weight = 15,6 kgTAPPING OPTIONS
• Standard Entry1 = 230 mm
• Standard Entry Cross = 714 mm
• Sides / Bottom Right-Left = 714 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 581 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 733 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 298 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 675 Watt
• Heat Output 90/70-20° ∆t=60°C = 851 Watt
• Heat Output 55/45-20° ∆t=30°C = 346 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 2304 Btu
• Heat Output 90/70-20° ∆t=60°C = 2904 Btu
• Heat Output 55/45-20° ∆t=30°C = 1180 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
