DL 5 Column Radiator 500x1314 Matt Black

Product Code : 2D5C05001314B3MS
Guarantee : 10 Year
TAXES Included
Price
:
155,678.76 TL
Discounted Price
:
85,623.32 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
INSTALLATION CONNECTION OPTIONS

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
09.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 5K

    • Material  = Steel

    • Height = 500 mm

    • Width   = 1314 mm

    • Color = Matt Black

    • Number of Columns = 5

    • Number of Sections  = 28 Pieces

    • Legs Needed If Free Standing = 3 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 128,5 mm

    • Wall Projection Distance  = 223 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 189 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 39,2 lt

    • Radiator Weight    = 53,2 kg

    TAPPING OPTIONS



    • Standard Entry1    = 430 mm

    • Standard Entry Cross = 1404 mm

    • Sides / Bottom Right-Left  = 1404 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 1980 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 2495 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 1014 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 2302 Watt

    • Heat Output 90/70-20° ∆t=60°C = 2901 Watt

    • Heat Output 55/45-20° ∆t=30°C = 1179 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 7855 Btu

    • Heat Output 90/70-20° ∆t=60°C = 9898 Btu

    • Heat Output 55/45-20° ∆t=30°C = 4022 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.



Other Colors
  • %45 Discount - DL 5 Column Radiator 500x1314 White
    AKS Seçenekleri
    DL 5 Column Radiator 500x1314 White ∆t50°C=1980 Kcal/h | ∆t60°C= 2496 Kcal/h | 28 Pipes | Heats 13-39 m2
    115,317.60 TL
    63,424.68 TL
  • %45 Discount - DL 5 Column Radiator 500x1314 Anthracite
    AKS Seçenekleri
    DL 5 Column Radiator 500x1314 Anthracite ∆t50°C=1980 Kcal/h | ∆t60°C= 2496 Kcal/h | 28 Pipes | Heats 13-39 m2
    155,678.76 TL
    85,623.32 TL
  • %45 Discount - DL 5 Column Radiator 500x1314 Matt Black
    AKS Seçenekleri
    DL 5 Column Radiator 500x1314 Matt Black ∆t50°C=1980 Kcal/h | ∆t60°C= 2496 Kcal/h | 28 Pipes | Heats 13-39 m2
    155,678.76 TL
    85,623.32 TL
  • %45 Discount - DL 5 Column Radiator 500x1314 Special Color Category 1
    AKS Seçenekleri
    DL 5 Column Radiator 500x1314 Special Color Category 1 ∆t50°C=1980 Kcal/h | ∆t60°C= 2496 Kcal/h | 28 Pipes | Heats 13-39 m2
    155,678.76 TL
    85,623.32 TL
  • %45 Discount - DL 5 Column Radiator 500x1314 Special Color Category 2
    AKS Seçenekleri
    DL 5 Column Radiator 500x1314 Special Color Category 2 ∆t50°C=1980 Kcal/h | ∆t60°C= 2496 Kcal/h | 28 Pipes | Heats 13-39 m2
    167,210.52 TL
    91,965.79 TL
