%45 Discount
Detay Banner

DL 6 Column Radiator 1200x440 Matt Black

Product Code : 2D6C12000440B3MS
Guarantee : 10 Year
TAXES Included
Price
:
81,043.74 TL
Discounted Price
:
44,574.06 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
INSTALLATION CONNECTION OPTIONS

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
06.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 6K

    • Material  = Steel

    • Height = 1200 mm

    • Width   = 440 mm

    • Color = Matt Black

    • Number of Columns = 6

    • Number of Sections  = 9 Pieces

    • Legs Needed If Free Standing = 2 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 149 mm

    • Wall Projection Distance  = 264 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 230 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 29,7 lt

    • Radiator Weight    = 46,8 kg

    TAPPING OPTIONS



    • Standard Entry1    = 1130 mm

    • Standard Entry Cross = 530 mm

    • Sides / Bottom Right-Left  = 530 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 1734 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 2185 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 888 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 2016 Watt

    • Heat Output 90/70-20° ∆t=60°C = 2541 Watt

    • Heat Output 55/45-20° ∆t=30°C = 1033 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 6879 Btu

    • Heat Output 90/70-20° ∆t=60°C = 8668 Btu

    • Heat Output 55/45-20° ∆t=30°C = 3523 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.



Other Colors
  • %45 Discount - Dl 6 Column Radiator 1200x440 White
    AKS Seçenekleri
    Dl 6 Column Radiator 1200x440 White ∆t50°C=1732 Kcal/h | ∆t60°C= 2204 Kcal/h | 9 Pipes | Heats 12-34 m2
    60,032.40 TL
    33,017.82 TL
  • %45 Discount - Dl 6 Column Radiator 1200x440 Anthracite
    AKS Seçenekleri
    Dl 6 Column Radiator 1200x440 Anthracite ∆t50°C=1732 Kcal/h | ∆t60°C= 2204 Kcal/h | 9 Pipes | Heats 12-34 m2
    81,043.74 TL
    44,574.06 TL
  • %45 Discount - DL 6 Column Radiator 1200x440 Matt Black
    AKS Seçenekleri
    DL 6 Column Radiator 1200x440 Matt Black ∆t50°C=1732 Kcal/h | ∆t60°C= 2204 Kcal/h | 9 Pipes | Heats 12-34 m2
    81,043.74 TL
    44,574.06 TL
  • %45 Discount - DL 6 Column Radiator 1200x440 Special Color Category 1
    AKS Seçenekleri
    DL 6 Column Radiator 1200x440 Special Color Category 1 ∆t50°C=1732 Kcal/h | ∆t60°C= 2204 Kcal/h | 9 Pipes | Heats 12-34 m2
    81,043.74 TL
    44,574.06 TL
  • %45 Discount - DL 6 Column Radiator 1200x440 Special Color Category 2
    AKS Seçenekleri
    DL 6 Column Radiator 1200x440 Special Color Category 2 ∆t50°C=1732 Kcal/h | ∆t60°C= 2204 Kcal/h | 9 Pipes | Heats 12-34 m2
    87,046.98 TL
    47,875.84 TL
