COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 6K
• Material = Steel
• Height = 1500 mm
• Width = 624 mm
• Color = Anthracite
• Number of Columns = 6
• Number of Sections = 13 Pieces
• Legs Needed If Free Standing = 2 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 149 mm
• Wall Projection Distance = 264 mm
• Section Width = 46 mm
• Radiator Depth = 230 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 52 lt
• Radiator Weight = 84,5 kgTAPPING OPTIONS
• Standard Entry1 = 1430 mm
• Standard Entry Cross = 714 mm
• Sides / Bottom Right-Left = 714 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 3086 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 3889 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 1581 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 3588 Watt
• Heat Output 90/70-20° ∆t=60°C = 4521 Watt
• Heat Output 55/45-20° ∆t=30°C = 1838 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 12243 Btu
• Heat Output 90/70-20° ∆t=60°C = 15427 Btu
• Heat Output 55/45-20° ∆t=30°C = 6269 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
