COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 6K
• Material = Steel
• Height = 1800 mm
• Width = 624 mm
• Color = Matt Black
• Number of Columns = 6
• Number of Sections = 13 Pieces
• Legs Needed If Free Standing = 3 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 149 mm
• Wall Projection Distance = 264 mm
• Section Width = 46 mm
• Radiator Depth = 230 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 61,1 lt
• Radiator Weight = 100,1 kgTAPPING OPTIONS
• Standard Entry1 = 1730 mm
• Standard Entry Cross = 714 mm
• Sides / Bottom Right-Left = 714 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 3679 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 4636 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 1884 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 4277 Watt
• Heat Output 90/70-20° ∆t=60°C = 5390 Watt
• Heat Output 55/45-20° ∆t=30°C = 2190 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 14594 Btu
• Heat Output 90/70-20° ∆t=60°C = 18389 Btu
• Heat Output 55/45-20° ∆t=30°C = 7473 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
