COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 6K
• Material = Steel
• Height = 2200 mm
• Width = 440 mm
• Color = Matt Black
• Number of Columns = 6
• Number of Sections = 9 Pieces
• Legs Needed If Free Standing = 3 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 149 mm
• Wall Projection Distance = 264 mm
• Section Width = 46 mm
• Radiator Depth = 230 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 51,3 lt
• Radiator Weight = 85,5 kgTAPPING OPTIONS
• Standard Entry1 = 2130 mm
• Standard Entry Cross = 530 mm
• Sides / Bottom Right-Left = 530 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 3089 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 3893 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 1582 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 3591 Watt
• Heat Output 90/70-20° ∆t=60°C = 4525 Watt
• Heat Output 55/45-20° ∆t=30°C = 1839 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 12253 Btu
• Heat Output 90/70-20° ∆t=60°C = 15439 Btu
• Heat Output 55/45-20° ∆t=30°C = 6274 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
Other Colors
-
%45 DiscountAKS SeçenekleriDL 6 Column Radiator 2200x440 White ∆t50°C=3090 Kcal/h | ∆t60°C= 3935 Kcal/h | 9 Pipes | Heats 20-60 m2
-
%45 DiscountAKS SeçenekleriDL 6 Column Radiator 2200x440 Anthracite ∆t50°C=3090 Kcal/h | ∆t60°C= 3935 Kcal/h | 9 Pipes | Heats 20-60 m2
-
%45 DiscountAKS SeçenekleriDL 6 Column Radiator 2200x440 Matt Black ∆t50°C=3090 Kcal/h | ∆t60°C= 3935 Kcal/h | 9 Pipes | Heats 20-60 m2
-
%45 DiscountAKS SeçenekleriDL 6 Column Radiator 2200x440 Special Color Category 1 ∆t50°C=3090 Kcal/h | ∆t60°C= 3935 Kcal/h | 9 Pipes | Heats 20-60 m2
-
%45 DiscountAKS SeçenekleriDL 6 Column Radiator 2200x440 Special Color Category 2 ∆t50°C=3090 Kcal/h | ∆t60°C= 3935 Kcal/h | 9 Pipes | Heats 20-60 m2
