COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 6K
• Material = Steel
• Height = 300 mm
• Width = 394 mm
• Color = Matt Black
• Number of Columns = 6
• Number of Sections = 8 Pieces
• Legs Needed If Free Standing = 2 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 149 mm
• Wall Projection Distance = 264 mm
• Section Width = 46 mm
• Radiator Depth = 230 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 8,8 lt
• Radiator Weight = 12 kgTAPPING OPTIONS
• Standard Entry1 = 230 mm
• Standard Entry Cross = 484 mm
• Sides / Bottom Right-Left = 484 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 430 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 542 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 221 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 499 Watt
• Heat Output 90/70-20° ∆t=60°C = 629 Watt
• Heat Output 55/45-20° ∆t=30°C = 256 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 1703 Btu
• Heat Output 90/70-20° ∆t=60°C = 2146 Btu
• Heat Output 55/45-20° ∆t=30°C = 872 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
