DL 6 Column Radiator 300x532 Matt Black

Product Code : 2D6C03000532B3MS
Guarantee : 10 Year
TAXES Included
Price
:
85,173.12 TL
Discounted Price
:
46,845.22 TL
<p>10 Year Warranty</p>
10 Years
Warranty
Kargo Bedava
2000€ +
Free Shipping
INSTALLATION CONNECTION OPTIONS

Standard / Cross Standard / Cross

Bottom Right - Bottom Left Bottom Right - Bottom Left

Lower Middle 50mm Lower Middle 50mm

Bottom Left 50mm Bottom Left 50mm

Bottom Right 50mm Bottom Right 50mm

Choose Quantity
Planned Delivery
:
05.04.2025 (45 Days)
İnstagram Takip Et
Campaign
  • Features
  • Downloads
  • Videos
  • Payment Options
  • Comments (0)

  • COLUMN RADIATOR TECHNICAL INFORMATION


    • Model = 6K

    • Material  = Steel

    • Height = 300 mm

    • Width   = 532 mm

    • Color = Matt Black

    • Number of Columns = 6

    • Number of Sections  = 11 Pieces

    • Legs Needed If Free Standing = 2 Pieces

    • Diameter of Vertical Pipes = 25 mm

    • Maximum Working Pressure = 10 bar

    • Wall to Center of Inlet = 149 mm

    • Wall Projection Distance  = 264 mm

    • Section Width    = 46 mm

    • Radiator Depth  = 230 mm

    • Radiator Thread Dimension     = 1/2"

    • Water Volume    = 12,1 lt

    • Radiator Weight    = 16,5 kg

    TAPPING OPTIONS



    • Standard Entry1    = 230 mm

    • Standard Entry Cross = 622 mm

    • Sides / Bottom Right-Left  = 622 mm

    • Bottom Middle Entrance = 50 mm

    • Bottom Right Entrance  = 50 mm

    • Bottom Left Entrance   = 50 mm

    Heat Output



    Kcal / h

    • Heat Output 75/65-20° ∆t=50°C = 590 Kcal/h

    • Heat Output 90/70-20° ∆t=60°C = 744 Kcal/h

    • Heat Output 55/45-20° ∆t=30°C = 303 Kcal/h

    Watts

    • Heat Output 75/65-20° ∆t=50°C = 686 Watt

    • Heat Output 90/70-20° ∆t=60°C = 865 Watt

    • Heat Output 55/45-20° ∆t=30°C = 352 Watt

    Btu

    • Heat Output 75/65-20° ∆t=50°C = 2341 Btu

    • Heat Output 90/70-20° ∆t=60°C = 2950 Btu

    • Heat Output 55/45-20° ∆t=30°C = 1199 Btu

    Warranty
    :
    10 Years
    Delivery Information
    :
    45 Day

  • Kolon Radyatörler İçin Duvara Montaj Videosu

    Radyatör Duvara Montaj Aparatları Fiyata Dahildir!





    Kolon Radyatörler İçin Ayak Montaj Videosu

    Ayaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.



Other Colors
  • %45 Discount - DL 6 Column Radiator 300x532 White
    AKS Seçenekleri
    DL 6 Column Radiator 300x532 White ∆t50°C=589 Kcal/h | ∆t60°C= 742 Kcal/h | 11 Pipes | Heats 4-12 m2
    63,091.20 TL
    34,700.16 TL
  • %45 Discount - DL 6 Column Radiator 300x532 Anthracite
    AKS Seçenekleri
    DL 6 Column Radiator 300x532 Anthracite ∆t50°C=589 Kcal/h | ∆t60°C= 742 Kcal/h | 11 Pipes | Heats 4-12 m2
    85,173.12 TL
    46,845.22 TL
  • %45 Discount - DL 6 Column Radiator 300x532 Matt Black
    AKS Seçenekleri
    DL 6 Column Radiator 300x532 Matt Black ∆t50°C=589 Kcal/h | ∆t60°C= 742 Kcal/h | 11 Pipes | Heats 4-12 m2
    85,173.12 TL
    46,845.22 TL
  • %45 Discount - DL 6 Column Radiator 300x532 Special Color Category 1
    AKS Seçenekleri
    DL 6 Column Radiator 300x532 Special Color Category 1 ∆t50°C=589 Kcal/h | ∆t60°C= 742 Kcal/h | 11 Pipes | Heats 4-12 m2
    85,173.12 TL
    46,845.22 TL
  • %45 Discount - DL 6 Column Radiator 300x532 Special Color Category 2
    AKS Seçenekleri
    DL 6 Column Radiator 300x532 Special Color Category 2 ∆t50°C=589 Kcal/h | ∆t60°C= 742 Kcal/h | 11 Pipes | Heats 4-12 m2
    91,482.24 TL
    50,315.23 TL
