COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 6K
• Material = Steel
• Height = 600 mm
• Width = 1406 mm
• Color = Matt Black
• Number of Columns = 6
• Number of Sections = 30 Pieces
• Legs Needed If Free Standing = 3 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 149 mm
• Wall Projection Distance = 264 mm
• Section Width = 46 mm
• Radiator Depth = 230 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 54 lt
• Radiator Weight = 81 kgTAPPING OPTIONS
• Standard Entry1 = 530 mm
• Standard Entry Cross = 1496 mm
• Sides / Bottom Right-Left = 1496 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 3019 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 3804 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 1546 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 3510 Watt
• Heat Output 90/70-20° ∆t=60°C = 4423 Watt
• Heat Output 55/45-20° ∆t=30°C = 1798 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 11977 Btu
• Heat Output 90/70-20° ∆t=60°C = 15092 Btu
• Heat Output 55/45-20° ∆t=30°C = 6133 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler Duvara Montaj Videosu
