TECHNICAL INFORMATION
• Model = Haiti
• Material =Steel
• Width= 400mm
• Height = 800mm
• Tapping Distance = 355 mm
• Color / Coating = Matte Black
• Horizontal Pipe Quantity= 13Pieces
• Horizontal Pipe Dimension = 22mm
• Vertical Collector Size= 30x40mm D Profile
• Maximum Working Pressure= 10bar
• Wall to Center of Inlet= 65-85 mm
• Wall Projection Distance=80-100 mm
• Towel Warmer Thread Dimension=1/2"
• Water Volume= 2,8lt
• Weight= 3,9kg
• Boxed Weight=4,4kg
• Box Size= 42x82x3,8cm
• Assembly Set Is Included In The Price,Included in the Box.
Prices do not include pipe sleeves pls. refer to page "Accessories" to see our rangeHeat Output
Kcal/h
• Heat Output 75/65-20°?t=50°C = 239Kcal/h
• Heat Output 90/70-20° ?t=60°C= 302Kcal/h
• Heat Output 55/45-20° ?t=30°C= 123Kcal/h
Watts
• Heat Output 75/65-20°?t=50°C= 278Watt
• Heat Output 90/70-20°?t=60°C= 350Watt
• Heat Output 55/45-20°?t=30°C= 143Watt
Btu
• Heat Output 75/65-20°?t=50°C= 948Btu
• Heat Output 90/70-20°?t=60°C= 1195Btu
• Heat Output 55/45-20°?t=30°C= 486Btu
Warranty:5 YearsDelivery Information:15 Day -
