Haiti Towel Warmer 500x700 White

TECHNICAL INFORMATION


• Model = Haiti

• Material = Steel

• Width = 500 mm

• Height = 700 mm

• Tapping Distance = 455 mm

• Color / Coating = White

• Horizontal Pipe Quantity = 12 Pieces

• Horizontal Pipe Dimension = 22 mm

• Vertical Collector Size = 30x40 mm D Profile

• Maximum Working Pressure = 10 bar

• Wall to Center of Inlet = 65-85

• Wall-Surface Distance = 80-100

• Towel Warmer Thread Dimension = 1/2"

• Water Volume = 2,9 lt

• Weight = 4 kg

• Gross Weight = 4,6 kg

• Box Size = 52x72x3,8 cm

• Assembly Set Is in the box and included In The Price

• Prices do not include valves pls. refer to page "Valves" to see our range

• Prices do not include pipe sleeve pls. refer to page "Accessories" to see our range

Heat Output

Kcal/h


• Heat Output 75/65-20° ∆t=50°C = 261 Kcal/h

• Heat Output 90/70-20° ∆t=60°C = 329 Kcal/h

• Heat Output 55/45-20° ∆t=30°C = 134 Kcal/h


Watt

• Heat Output 75/65-20° ∆t=50°C = 303 Watt

• Heat Output 90/70-20° ∆t=60°C = 383 Watt

• Heat Output 55/45-20° ∆t=30°C = 156 Watt


Btu

• Heat Output 75/65-20° ∆t=50°C = 1036 Btu

• Heat Output 90/70-20° ∆t=60°C = 1306 Btu

• Heat Output 55/45-20° ∆t=30°C = 531 Btu
