TECHNICAL INFORMATION
• Model = Haiti
• Material =Steel
• Width= 500mm
• Height = 800mm
• Tapping Distance = 455 mm
• Color / Coating = Chrome
• Horizontal Pipe Quantity= 13Pieces
• Horizontal Pipe Dimension = 22mm
• Vertical Collector Size= 30x40mm D Profilee
• Maximum Working Pressure= 10bar
• Wall to Center of Inlet= 65-85 mm
• Wall Projection Distance=80-100 mm
• Towel Warmer Thread Dimension=1/2"
• Water Volume= 3,2lt
• Weight= 4,4kg
• Boxed Weight=5,1kg
• Box Size= 52x82x3,8cm
• Assembly Set Is Included In The Price,Included in the Box.
• Prices do not include valves pls. refer to page "Valves" to see our range
• Prices do not include pipe sleeves pls. refer to page "Accessories" to see our rangeHeat Output
Kcal/h
• Heat Output 75/65-20°?t=50°C = 187Kcal/h
• Heat Output 90/70-20° ?t=60°C= 236Kcal/h
• Heat Output 55/45-20° ?t=30°C= 96Kcal/h
Watts
• Heat Output 75/65-20°?t=50°C= 217Watt
• Heat Output 90/70-20°?t=60°C= 274Watt
• Heat Output 55/45-20°?t=30°C= 112Watt
Btu
• Heat Output 75/65-20°?t=50°C= 742Btu
• Heat Output 90/70-20°?t=60°C= 935Btu
• Heat Output 55/45-20°?t=30°C= 380Btu
Warranty:5 YearsDelivery Information:1 Day -
Other Colors
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 White 13 Pipes | 455mm Aks |∆t50°C= 286 Kcal/h | ∆t60°C= 361 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Anthracite 13 Pipes | 455mm Aks |∆t50°C= 286 Kcal/h | ∆t60°C= 361 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Matte Black 13 Pipes | 455mm Aks |∆t50°C= 286 Kcal/h | ∆t60°C= 361 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Chrome 13 Pipes | 455mm Aks |∆t50°C= 186 Kcal/h | ∆t60°C= 234 Kcal/h | Heats1-4 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Gold 13 Pipes | 455mm Aks |∆t50°C= 186 Kcal/h | ∆t60°C= 234 Kcal/h | Heats1-4 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Copper Antique 13 Pipes | 455mm Aks |∆t50°C= 186 Kcal/h | ∆t60°C= 234 Kcal/h | Heats1-4 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 500x800 Wood Effect 13 Pipes | 455mm Aks |∆t50°C= 286 Kcal/h | ∆t60°C= 361 Kcal/h | Heats2-6 m2
