TECHNICAL INFORMATION
• Model = Haiti
• Material =Steel
• Width= 600mm
• Height = 1200mm
• Tapping Distance = 555 mm
• Color / Coating = Anthracite
• Horizontal Pipe Quantity= 22Pieces
• Horizontal Pipe Dimension = 22mm
• Vertical Collector Size= 30x40mm D Profile
• Maximum Working Pressure= 10bar
• Wall to Center of Inlet= 65-85 mm
• Wall Projection Distance=80-100 mm
• Towel Warmer Thread Dimension=1/2"
• Water Volume= 5,9lt
• Weight= 8kg
• Boxed Weight=8,8kg
• Box Size= 62x122x3,8cm
• Assembly Set Is Included In The Price,Included in the Box.
Prices do not include pipe sleeves pls. refer to page "Accessories" to see our rangeHeat Output
Kcal/h
• Heat Output 75/65-20°?t=50°C = 518Kcal/h
• Heat Output 90/70-20° ?t=60°C= 653Kcal/h
• Heat Output 55/45-20° ?t=30°C= 266Kcal/h
Watts
• Heat Output 75/65-20°?t=50°C= 601Watt
• Heat Output 90/70-20°?t=60°C= 758Watt
• Heat Output 55/45-20°?t=30°C= 308Watt
Btu
• Heat Output 75/65-20°?t=50°C= 2052Btu
• Heat Output 90/70-20°?t=60°C= 2586Btu
• Heat Output 55/45-20°?t=30°C= 1051Btu
Warranty:5 YearsDelivery Information:15 Day -
Other Colors
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 White 22 Pipes | 555mm Aks |∆t50°C= 519 Kcal/h | ∆t60°C= 654 Kcal/h | Heats3-10 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Anthracite 22 Pipes | 555mm Aks |∆t50°C= 519 Kcal/h | ∆t60°C= 654 Kcal/h | Heats3-10 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Chrome 22 Pipes | 555mm Aks |∆t50°C= 337 Kcal/h | ∆t60°C= 425 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Gold 22 Pipes | 555mm Aks |∆t50°C= 337 Kcal/h | ∆t60°C= 425 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Copper Antique 22 Pipes | 555mm Aks |∆t50°C= 337 Kcal/h | ∆t60°C= 425 Kcal/h | Heats2-6 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Wood Effect 22 Pipes | 555mm Aks |∆t50°C= 519 Kcal/h | ∆t60°C= 654 Kcal/h | Heats3-10 m2
-
%45 DiscountAKS SeçenekleriHaiti Towel Warmer 600x1200 Matte Black 22 Pipes | 555mm Aks |∆t50°C= 519 Kcal/h | ∆t60°C= 654 Kcal/h | Heats3-10 m2
