TECHNICAL INFORMATION
• Model = 10V
• Material =Steel
• Height=600 mm
• Width=2438 mm
• Color/Coating=Matte Black RAL9005
• Number of Sections=33 Pieces
• Total Number of Profiles (Front + Back)=33+0 Pieces
• Profile Dimension=70x11 mm
• Collector Dimension=38 mm
• Maximum Working Pressure=4,5 bar
• Radiator Depth=48 mm
• Wall to Center of Inlet=40 mm
• Wall Projection Distance=69 mm
• Radiator Thread Dimension=1/2"
• Water Volume=14 lt
• Weight=37,6 kg
• Boxed Weight=42,29 kg
• Box Size=248x65x8,6 cmTAPPING OPTIONS
• Standard Entry1 =2528 mm
• Standard Entry2 =550 mm
• Standard Entry Cross =2528 mm
• Bottom Middle Entrance=50mm
• Bottom Right Entrance=50mm
• Bottom Left Entrance=50mmHeat Output
Kcal / h
• Heat Output 75/65-20°?t=50°C = 1568 Kcal/h
• Heat Output 90/70-20° ?t=60°C=1976Kcal/h
• Heat Output 55/45-20° ?t=30°C=803 Kcal/h
Watts
• Heat Output 75/65-20°?t=50°C=1823 Watt
• Heat Output 90/70-20°?t=60°C=2297 Watt
• Heat Output 55/45-20°?t=30°C=934 Watt
Btu
• Heat Output 75/65-20°?t=50°C=6221 Btu
• Heat Output 90/70-20°?t=60°C=7839 Btu
• Heat Output 55/45-20°?t=30°C=3186 Btu
Warranty:10 YearsDelivery Information:21 Day
