TECHNICAL INFORMATION
• Model = 20V
• Material =Steel
• Height=1800 mm
• Width=884 mm
• Color/Coating=Bright White RAL9016
• Number of Sections=12 Pieces
• Total Number of Profiles (Front + Back)=12+12 Pieces
• Profile Dimension=70x11 mm
• Collector Dimension=38 mm
• Maximum Working Pressure=4,5 bar
• Radiator Depth=58 mm
• Wall to Center of Inlet=64 mm
• Wall Projection Distance=93 mm
• Radiator Thread Dimension=1/2"
• Water Volume=23,1 lt
• Weight=69,9 kg
• Boxed Weight=74,98 kg
• Box Size=93x185x9,6 cmTAPPING OPTIONS
• Standard Entry1 =974 mm
• Standard Entry2 =1750 mm
• Standard Entry Cross =974 mm
• Bottom Middle Entrance=50mm
• Bottom Right Entrance=50mm
• Bottom Left Entrance=50mmHeat Output
Kcal / h
• Heat Output 75/65-20°?t=50°C = 2143 Kcal/h
• Heat Output 90/70-20° ?t=60°C=2701Kcal/h
• Heat Output 55/45-20° ?t=30°C=1098 Kcal/h
Watts
• Heat Output 75/65-20°?t=50°C=2491 Watt
• Heat Output 90/70-20°?t=60°C=3139 Watt
• Heat Output 55/45-20°?t=30°C=1276 Watt
Btu
• Heat Output 75/65-20°?t=50°C=8500 Btu
• Heat Output 90/70-20°?t=60°C=10710 Btu
• Heat Output 55/45-20°?t=30°C=4352 Btu
Warranty:10 YearsDelivery Information:21 Day
