Type 20V Decorative Radiator 900x1698 Anthracite

Name: Type 20V Decorative Radiator 900x1698 Anthracite
SKU: 220V09001698B2TS
Price: 46558.88 TRY
Availability: InStock

Product Code : 220V09001698B2TS

Guarantee : 10 Year

TAXES Included

Price

84,652.50 TL

Discounted Price

46,558.88 TL

10 Years
Warranty

2000€ +
Free Shipping

Options

Standard Entry

Bottom Middle 50mm

Bottom Left 50mm

Bottom Right 50mm

Choose Quantity

Add to Cart

Planned Delivery

20.01.2025 (21 Days)

Add Comment Price Allert Add to Favorites

Features
Downloads
Payment Options
Comments (0)

TECHNICAL INFORMATION
• Model = 20V

• Material =Steel

• Height=900 mm

• Width=1698 mm

• Color/Coating=Anthracite

• Number of Sections=23 Pieces

• Total Number of Profiles (Front + Back)=23+23 Pieces

• Profile Dimension=70x11 mm

• Collector Dimension=38 mm

• Maximum Working Pressure=4,5 bar

• Radiator Depth=58 mm

• Wall to Center of Inlet=64 mm

• Wall Projection Distance=93 mm

• Radiator Thread Dimension=1/2"

• Water Volume=23,8 lt

• Weight=69,3 kg

• Boxed Weight=74,19 kg

• Box Size=174x95x9,6 cm

TAPPING OPTIONS

• Standard Entry1 =1788 mm

• Standard Entry2 =850 mm

• Standard Entry Cross =1788 mm

• Bottom Middle Entrance=50mm

• Bottom Right Entrance=50mm

• Bottom Left Entrance=50mm

Heat Output

Kcal / h

• Heat Output 75/65-20°?t=50°C = 2263 Kcal/h

• Heat Output 90/70-20° ?t=60°C=2852Kcal/h

• Heat Output 55/45-20° ?t=30°C=1159 Kcal/h

Watts

• Heat Output 75/65-20°?t=50°C=2631 Watt

• Heat Output 90/70-20°?t=60°C=3316 Watt

• Heat Output 55/45-20°?t=30°C=1348 Watt

Btu

• Heat Output 75/65-20°?t=50°C=8977 Btu

• Heat Output 90/70-20°?t=60°C=11312 Btu

• Heat Output 55/45-20°?t=30°C=4597 Btu

Warranty

:

10 Years

Delivery Information

:

21 Day
