COLUMN RADIATOR TECHNICAL INFORMATION
• Model = 4K
• Material = Steel
• Height = 1000 mm
• Width = 2326 mm
• Color = Matt Black
• Number of Columns = 4
• Number of Sections = 50 Pieces
• Legs Needed If Free Standing = 4 Pieces
• Diameter of Vertical Pipes = 25 mm
• Maximum Working Pressure = 10 bar
• Wall to Center of Inlet = 108 mm
• Wall Projection Distance = 182 mm
• Section Width = 46 mm
• Radiator Depth = 148 mm
• Radiator Thread Dimension = 1/2"
• Water Volume = 95 lt
• Radiator Weight = 145 kgTAPPING OPTIONS
• Standard Entry1 = 930 mm
• Standard Entry Cross = 2416 mm
• Sides / Bottom Right-Left = 2416 mm
• Bottom Middle Entrance = 50 mm
• Bottom Right Entrance = 50 mm
• Bottom Left Entrance = 50 mmHeat Output
Kcal / h
• Heat Output 75/65-20° ∆t=50°C = 5676 Kcal/h
• Heat Output 90/70-20° ∆t=60°C = 7152 Kcal/h
• Heat Output 55/45-20° ∆t=30°C = 2907 Kcal/h
Watts
• Heat Output 75/65-20° ∆t=50°C = 6600 Watt
• Heat Output 90/70-20° ∆t=60°C = 8316 Watt
• Heat Output 55/45-20° ∆t=30°C = 3380 Watt
Btu
• Heat Output 75/65-20° ∆t=50°C = 22520 Btu
• Heat Output 90/70-20° ∆t=60°C = 28376 Btu
• Heat Output 55/45-20° ∆t=30°C = 11531 Btu
Warranty:10 YearsDelivery Information:45 Day Kolon Radyatörler İçin Duvara Montaj Videosu
Radyatör Duvara Montaj Aparatları Fiyata Dahildir!
Kolon Radyatörler İçin Ayak Montaj VideosuAyaklar Ayrı Satılmakta Olup, Radyatörünüzün Ölçüsüne Göre, Ürün Açıklamalarında Belirtilen Miktarda Ayağı Aksesuarlar Bölümünden Sepete Ekleyip Alabilirsiniz.
